Wireless Remote Control HK-980
| Technical Data: | ||
| Input Power | DC10V-14V | |
| Standby Current | <5MA RF | |
| Frequency | 315M or 433M | |
| RF working mode | super heterodyne | |
| Receive sensitivity | >97dbm | |
| Transmitting distance | >100m ( open space) | |
| Decoding mode | MCU software decoding | |
| Remote storage | 50pcs | |
| Support remote type | Learning code, Fixed code(Rolling code can be design) | |
| Working mode | Momentary, Toggle, Latching Time delay (5s ,10s ,15s ) | |
| Writing Type | fixed terminal | |
| Output Terminal | NO , NC , COM | |
| Dimension of PCB | 35*30*18mm (L,W,H) | |
Wiring diagram 1: +V : 12V + input ; – V: 12V – input ; NO: Output , normal open; COM:Output , common ; NC: Output , normal close; About Working mode: Momentary:Push the remote button , the relay connects, release the remote button , the relay dis-connects. Toggle:Push once the remote button , the relay connects , push twice the remote button , the relay dis-connects . Latching:Push the remote button A, the relay connects, push the remote button B, the relay dis-connect. Tiem delay mode :Push the remote control button , the relay connects , from when release the remote button , after 5s or 10s or 15s , the relay disconnect automatically . Clearing the code : Push the learning button on the receivers for 8 times , the codes will be cleaned . After clearning the code, all the remote control cannot work any more. Learning the code :(momentary) Push the learning key on the receiver once time , it comes into momentary setting mode . Wait for a moment , the LED will be off , it comes into learning state . Push the remote button , LED indicator on the receiver board will flash then come off . After 3 seconds, the LED indicator will be on again , learning successfully . Learning the code : ( Toggle ) Push the learning key on the receiver twice time , it comes into toggle setting mode Wait for a moment , the LED will be off , it comes into learning state . Push the remote button,LED indicator on the receiver board will flash then come off. After 3 seconds , the LED indicator will be on again , learning successfully . Learning the code 🙁 Latching ) Note: When you choose for latching mode , in order to learn more remote control , you need to learn two different button , the first time learnt is for “ON”, the second time learnt for “OFF”. For example : button A = ON , button B = OFF Push the learning key on the receiver triple time , it comes into latching mode . Wait for a moment , the LED indicator on the receiver board will flash then come off. Push the remote button A . LED flash for 5 times . Push the remote button B . Led flash for 5 times . After 3 seconds , the LED indicator will be on again , learning successfully. A = ON , B = OFF . Learning the code 🙁 Time delay mode ) Push the learning key on the receiver forth time , the time dealy for 5 seconds . Push the learning key on the receiver fifth time , the time delay for 10 seconds . Push the learning key on the receiver sixth time , the time delay for 15 seconds . The LED indicator will be off . Push the remote button , LED flashes and off . After 3 seconds , the LED indicator will be on again , learning successfully . NOTE: The system can store for 50 pcs of remotes , if the remote get more than 50pcs , the initial remote control will be lost . PACKAGE 1 SWITCH 1 RECEIVER Wireless Remote Control HK-980
