JEVE 25.6V 200Ah LiFePO4 Lithium Battery
JEVE 25.6V 200Ah LiFePO4 Lithium Battery
- Brand: JEVE
- Model: MAL25.6V200Ah
- Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
- Nominal Voltage: 25.6V
- Typical Capacity: 200Ah
- Nominal Energy: 5120Wh (5.12kWh)
- Cycle Life: More than 4,000 cycles at 80% DOD
- Bluetooth Monitoring: Capacity, voltage, current, cycles, SOC, SOH, cell voltage, temperature and battery status
- Maximum Continuous Charging Current: 150A
- Maximum Continuous Discharging Current: 150A
- Protection Class: IP65
- Suitable for compatible solar systems, RV and camper, marine, UPS backup and off-grid applications
| Specification | Details |
|---|---|
| Brand | JEVE |
| Model | MAL25.6V200Ah |
| Product Type | Lithium Iron Phosphate Battery Pack |
| Battery Chemistry | LiFePO4 |
| Nominal Voltage | 25.6V |
| Typical Capacity | 200Ah (25°C, 0.2C) |
| Typical Energy | 5120Wh (5.12kWh) |
| Gravimetric Energy Density | About 120Wh/kg |
| Dimensions (L × W × H) | 522 × 268 × 223 mm (±3 mm; rated parameters) |
| Appearance Dimensions | 522 × 268 × 223 ± 2 mm |
| Reference Weight | 37.0 ± 1 kg |
| Case Material | ABS |
| Bluetooth Monitoring | Capacity, voltage, current, cycles, SOC, SOH, cell voltage, temperature and status |
| Cycle Life | >4000 cycles (80% DOD) |
| Charging Method | CC/CV |
| Charging Voltage Range | 28.6–29.2V |
| Maximum Continuous Charging Current | 150A (rated parameters section) |
| Maximum Continuous Discharging Current | 150A (rated parameters section) |
| Discharge Pulse Current | 200A for 3 seconds |
| End of Discharge Voltage | 21.6V |
| Charging Temperature | 0°C to 60°C |
| Discharging Temperature | −20°C to 65°C |
| Storage Temperature | −10°C to 40°C |
| Protection Class | IP65 |
| BMS Protection Functions | Overcharge, over-discharge, overcurrent and short-circuit protection; temperature protection details are included in the datasheet |
| BMS Maximum Continuous Charging Current | 100A (BMS table, page 4) |
| BMS Maximum Continuous Discharging Current | 200A (BMS table, page 4) |
| Overcharge Detection Voltage | 3.75 ± 0.05V |
| Overcharge Release Voltage | 3.45 ± 0.05V |
| Over-discharge Detection Voltage | 2.3 ± 0.05V |
| Over-discharge Release Voltage | 2.90 ± 0.10V |
| Overcharge Current Protection | 110A; 3-second delay |
| Over-discharge Current Protection 1 | 200A; 3-second delay |
| Over-discharge Current Protection 2 | 400A; 300–600 ms delay |
| Short-Circuit Protection | Supported |
| Internal Resistance | ≤35mΩ |
| Capacity Test Requirement | Capacity ≥200Ah |
| Charge Retention Capability | ≥80% under specified 28-day test conditions |
| Charge Recovery | ≥90% |
| Warranty | 1 Year |
